CE/ISO9001:2008 approved crushing machine with 12 months guaranteed
- Cone Crusher Machine
Cone Crusher Machine
- China
- CE, ISO9001:2008, SGS
- One set CE/ISO9001:2008 approved crushing machine with 12 months guaranteed
- [email protected]
- Varies
- Within 5 working days
- paypal,UnionPay, Visa/MasterCard, Amex, Discover,T/T
- 87
-
Shandong Brawny Industrial Co.,Ltd2020-07-10 09:46:19
Welcome to my shop! Glad to serve you! Please send your question!
Product Description
CE/ISO9001:2008 approved crushing machine with 12 months guaranteed
Zhengzhou CE/ISO9001:2008 approved crushing machine with 12 months guaranteed Mining Machinery Co., Ltd is professional factory with rich experiences in manufacturing Jaw Crusher, Impact Crusher, Impact Fine Crusher, Cone Crusher, Hammer Crusher, Hydraulic cone crusher, Compound Crusher, Two-Roller Crusher and so on. Welcome to visit and cooperate with us.
Application & technical parameter of Jaw Crusher
Jaw crushers are widely used for mining, metallugy, construction, highway, railway, irrigation works, chemical industry and materials with compression strength no more than 350 Mpa for primary crushing process.
| Type | Feeding opening(mm) | Max feeding size(mm) | Adjustment scopes(mm) | Capacity(T/H) |
Rotating speed of mainshaft (r/min) |
Motor Power (KW) |
Dimensions(LxWxH) (mm) |
Weight (T) |
| PEF 150×250 | 150X250 | 125 | 10-40 | 1-3 | 285 | 7.5 | 922×745×933 | 0.7 |
| PEF 200×300 | 200X300 | 165 | 20-70 | 2-8 | 265 | 11 | 1056×1100×1120 | 0.8 |
| PEF 250×400 | 250×400 | 210 | 20-80 | 5-20 | 310 | 18.5 | 1108×1142×1392 | 3 |
| PEF 400×600 | 400×600 | 340 | 40-90 | 10-40 | 275 | 30 | 1700×1732×1392 | 7.2 |
| PEF 350×750 | 350×750 | 290 | 30-55 | 20-50 | 300 | 37 | 1900×1806×1808 | 8.9 |
| PEF 500×750 | 500×750 | 425 | 50-100 | 34-68 | 275 | 55 | 2050×1860×2145 | 11.32 |
| PEF 600×900 | 600×900 | 480 | 75-200 | 40-120 | 255 | 75 | 2792×2168×2250 | 17.6 |
| PEF 750×1060 | 750×1060 | 630 | 80-200 | 80-160 | 250 | 90 | 4180×2560×3070 | 30.53 |
| PEF 900×1200 | 900×1200 | 750 | 100-200 | 110-200 | 250 | 110 | 5200×2900×3500 | 50 |
| PEF1200×1500 | 120×150 | 1020 | 150-300 | 220-400 | 180 | 160 | 4200×3300×3500 | 106 |
| PEX 150×750 | 150×750 | 125 | 10-40 | 5-15 | 300 | 15 | 1220×1480×1180 | 3.6 |
| PEX 250×1000 | 250×1000 | 210 | 15-55 | 10-32 | 300 | 37 | 1580×1992×1380 | 7.35 |
| PEX 250×1200 | 250×1200 | 210 | 15-60 | 12-38 | 300 | 37 | 1730×2192×1380 | 8.7 |
| PEX 300×1300 | 300×1300 | 250 | 20-90 | 16-65 | 300 | 55 | 1930×2400×1747 | 11.6 |
Main technical parameter of Impact Crusher
Specifications Of Impact Crusher | ||||||
Type |
Spec. |
Feeder Opening (mm) |
Feeding |
Crushing |
Motor |
Weight |
PF-0807 |
Φ850×700 |
400×730 |
300 |
15-30 |
30-45 |
8 |
PF-1008 |
Φ1000×800 |
400×830 |
300 |
30-50 |
37-55 |
10 |
PF-1010 |
Φ1000×1050 |
400×1080 |
350 |
50-80 |
55-75 |
12 |
PF-1210 |
Φ1250×1050 |
400×1080 |
350 |
70-120 |
110-132 |
14 |
PF-1214 |
Φ1250×1400 |
400×1430 |
350 |
130-180 |
132-160 |
18.6 |
PF-1315 |
Φ1320×1500 |
860×1520 |
500 |
160-250 |
180-260 |
19 |
PF-1320 |
Φ1320×2000 |
860×2030 |
500 |
300-350 |
300-375 |
24 |
Main technical parameter of Impact Fine Crusher
| Model | PCX0804 | PCX0808 | PCX1010 | PCX1212 | PCX1414 | PCX1616 | PCX1818 |
| Feeding size of machine (mm) | 400×185 | 550×330 | 1000×350 | 1200×450 | 1500×500 | 1600×550 | 1800×800 |
| Max. feeding size of material (mm) | ≤120 | ≤180 | ≤180 | ≤180 | ≤190 | ≤190 | ≤190 |
| Size of discharging material (mm) | ≤5 | ≤5 | ≤5 | ≤5 | ≤5 | ≤5 | ≤5 |
|
Adjusting width of discharge gap of the gate (mm) |
5-20 | 5-20 | 5-20 | 5-20 | 5-20 | 5-20 | 5-20 |
| Cement clinker (T/H) | 20-30 | 35-45 | 45-55 | 100-110 | 100-150 | 170-210 | 250-270 |
| Limestone (T/H) | 30-45 | 60-65 | 60-75 | 90-100 | 100-150 | 190-250 | 280-310 |
| Glass sand (T/H) | 35-45 | 55-65 | 65-75 | 90-120 | 120-150 | 190-250 | 280-310 |
| Power (kw) | 30-37 | 37-55 | 55-75 | 110-132 | 132-180 | 180-260 | 240-320 |
| Weight (T) | 4200 | 6500 | 10600 | 15500 | 20000 | 26800 | 30000 |
Main Technical Parameter of Cone Crusher
| Model |
Diameter of crushing cone (mm) |
Max feed size (mm) |
Adjusting rangeof output size (mm) |
Capacity (t/h) |
Motor Power (kw) |
Rotary Speed (r/min) |
Weight (t) |
Overall dimension (mm) |
|
| PYB | 900 | 900 | 115 | 15-50 | 50-90 | 55 | 333 | 11.2 | 2692×1640×2350 |
| PYZ | 60 | 5-12 | 20-65 | 11.2 | 2692×1640×2350 | ||||
| PYD | 50 | 3-13 | 15-50 | 11.3 | 2692×1640×2350 | ||||
| PYB | 1200 | 1200 | 145 | 20-50 | 110-168 | 110 | 300 | 24.7 | 2790×1878×2844 |
| PYZ | 100 | 8-25 | 42-135 | 25 | 2790×1878×2844 | ||||
| PYD | 50 | 3-15 | 18-105 | 25.3 | 2790×1878×2844 | ||||
| PYB | 1750 | 1750 | 215 | 25-50 | 280-480 | 160 | 245 | 50.3 | 3910×2894×3809 |
| PYZ | 185 | 10-30 | 115-320 | 50.3 | 3910×2894×3809 | ||||
| PYD | 85 | 5-13 | 75-230 | 50.2 | 3910×2894×3809 | ||||
| PYB | 2200 | 2200 | 300 | 30-60 | 59-1000 | 260 | 220 | 80 | 4622×3302×4470 |
| PYZ | 230 | 10-30 | 200-580 | 80 | 4622×3302×4470 | ||||
| PYD | 100 | 5-15 | 120-340 | 81.4 | 4622×3302×4470 | ||||
Main Technical Parameter of Hydraulic Cone Crusher
| Model | Cavity Type |
Max feeding Size (mm) |
Adjusting Range of Output Size (mm) |
Capacity (t/h) |
Motor Power (kw) |
Weight (t) |
Overall Dimension (mm) |
| HCC-75B | Fine | 85 | 9-22 | 46-94 | 75 | 14.2 | 2656×1746×2241 |
| Coarse | 150 | 13-38 | 61-168 | ||||
| Extra Coarse | 152 | 25-38 | 122-168 | ||||
| HCC-75D | Fine | 35 | 3-13 | 28-93 | 75 | 14.7 | 2656×1746×2241 |
| Medium | 65 | 5-16 | 37-103 | ||||
| Coarse | 85 | 6-19 | 61-133 | ||||
| HCC-160B | Fine | 115 | 13-31 | 112-189 | 160 | 25.9 | 2983×2354×3156 |
| Medium | 178 | 16-38 | 136-261 | ||||
| Coarse | 205 | 19-51 | 177-359 | ||||
| Extra Coarse | 220 | 25-51 | 243-369 | ||||
| HCC-160D | Fine | 54 | 3-16 | 37-168 | 160 | 26.4 | 2983×2354×3156 |
| Medium | 76 | 6-16 | 84-168 | ||||
| Coarse | 89 | 8-25 | 112-234 | ||||
| Extra Coarse | 113 | 16-25 | 215-243 | ||||
| HCC-220B | Fine | 178 | 16-38 | 186-337 | 220 | 50 | 3911×2870×3771 |
| Medium | 205 | 22-51 | 266-430 | ||||
| Coarse | 228 | 25-64 | 308-654 | ||||
| Extra Coarse | 313 | 38-64 | 444-664 | ||||
| HCC-220D | Fine | 60 | 5-13 | 93-215 | 220 | 51 | 3911×2870×3771 |
| Medium | 76 | 6-19 | 140-289 | ||||
| Coarse | 113 | 10-25 | 16-346 | ||||
| Extra Coarse | 125 | 13-25 | 261-346 | ||||
| HCC-315B | Fine | 236 | 19-38 | 392-748 | 315 | 88 | 4613×3302×4638 |
| Medium | 284 | 25-51 | 626-1028 | ||||
| Coarse | 314 | 31-64 | 813-1308 | ||||
| Extra Coarse | 391 | 38-64 | 906-1402 | ||||
| HCC-315D | Fine | 89 | 5-16 | 196-420 | 315 | 90 | 4613×3302×4638 |
| Medium | 113 | 10-19 | 365-523 | ||||
| Coarse | 151 | 13-25 | 468-617 | ||||
| Extra Coarse | 172 | 16-25 | 523-673 |
Main technical parameter of VSI Shaft Impact Crusher
Model |
Max Feed Size (mm) |
Speed of Rotor (r/min) |
Capacity (t/h) |
Motor Power (Kw) |
Overall Dimensions (L×W×H)(mm) |
Weight (Kg) |
VI-1000 |
30 (50) |
2300-3200 |
3-20 |
7.5-22 |
2200×1300×1880 |
≤2800 |
VI-2000 |
40 (60) |
2000-2500 |
10-40 |
30-45 |
2200×1500×1580 |
≤3350 |
VI-3000 |
45 (70) |
1700-2000 |
30-60 |
75-90 |
3600×1600×1810 |
≤4900 |
VI-4000 |
55 (70) |
1400-1620 |
50-90 |
110-150 |
3700×1800×1900 |
≤6900 |
VI-5000 |
65 (80) |
1330-1530 |
80-150 |
180-264 |
4000×2160×2230 |
≤11640 |
VI-6000 |
80 (100) |
1200-1400 |
120-250 |
264-320 |
5200×2660×2560 |
≤15170 |
VI-7000 |
80 (100) |
1000-1200 |
180-350 |
320-400 |
5300×2660×2830 |
≤16280 |
VI-8000 |
100 (150) |
1000-1100 |
250-500 |
440-500 |
6000×3000×3420 |
≤23450 |
VI-8000(II) |
100 (150) |
1000-1100 |
400-650 |
500-630 |
6000×3000×3590 |
≤25050 |
VI-9000 |
110 (150) |
900-1000 |
550-1200 |
630-740 |
6200×3300×3890 |
≤33100 |
Main technical parameters of Hammer Crusher
| Types |
Feeding Size (mm) |
Output Size(mm) |
Capacity (T/H) |
Motor Power (kw) |
Machine Weight (T) |
| PC 400×300 | ≤100 | ≤10 | 5-10 | 11 | 0.8 |
| PC 600×400 | ≤120 | ≤15 | 10-25 | 18.5 | 1.5 |
| PC 800×600 | ≤120 | ≤15 | 20-40 | 55 | 3.1 |
| PC 1000×800 | ≤200 | ≤13 | 40-60 | 75 | 7.9 |
| PC 1000×1000 | ≤200 | ≤15 | 60-100 | 110 | 8.65 |
| PC 1300×1200 | ≤250 | ≤19 | 100-180 | 220 | 16.6 |
Main technical parameter of Compound Crusher
Model |
PFL-800 |
PFL-1000 |
PFL-1250 |
PFL-1500 |
PFL-1750 |
PFL-2000 |
|
Material-in size (mm) |
200 |
220 |
||||
|
Material-out size (mm) |
60-90% |
60-90% |
60-90% |
|||
Capacity (t/h) |
10-20 |
20-40 |
40-70 |
70-100 |
130-190 |
200-260 |
Motor power (kw) |
22 |
45-55 |
75 |
90-110 |
132-160 |
185 |
|
Main shaft speed (r/min) |
934 |
769 |
530 |
495 |
424 |
370 |
|
Overall dimension (l×w×h)(m) |
2.1×1.2×1.7 |
2.6×1.4×1.9 |
2.8×1.6×2.1 |
3.1×1.9×2.2 |
3.71×2.36×2.39 |
4.1×2.66×2.62 |
Main technical parameter of Two-Roller Crusher
| Types | Material-in size (mm) | Material-out size (mm) | Capacity (t/h) | Motor power (kw) | Weight (kg) |
| 2PG-400×250 | ≤25 | 1-8 | 5-10 | 11 | 1500 |
| 2PG-610×400 | ≤40 | 1-20 | 13-35 | 30 | 4500 |
| 2PG-750×500 | ≤40 | 2-20 | 15-40 | 37 | 12250 |
| 2PG-900×500 | ≤40 | 3-40 | 20-50 | 44 | 14000 |
Cone Crusher Machine is a complete mobile crushing and screening plant which consists of raw material bins which located on one or more trailers, vibrating feeders, primary crushers, multi-layer vibrating screens, secondary crushers, fine crushers, mobile belt conveyors, sand washers, electric control systems and etc.; CE/ISO9001:2008 approved crushing machine with 12 months guaranteed is applicable to the mobile crushing processes in highway, railway, metallurgy, ore mine, construction and other industries.
YHGGUH
Cone Crusher Machine can be used in Pebble, rock (the limestone, granite, basalt, aluminum, andesite, etc.), ore tailings, and slags. CE/ISO9001:2008 approved crushing machine with 12 months guaranteed can be used in Building aggregate, highway, asphalt concrete and cement aggregate production. Cone Crusher Machine As well as stone reshaping production in water conservancy and hydropower engineering field, highway, railway, bridge, passenger line, airport runway, municipal engineering and high-rise buildings finely process of mining areas.CE/ISO9001:2008 approved crushing machine with 12 months guaranteed
YHGUJ
