Home>Products>Jaw Crusher Machine>China Reliable quality and Energy Saving jaw crusher machine for Chalk
China Reliable quality and Energy Saving jaw crusher machine for Chalk
- Jaw Crusher Machine
Jaw Crusher Machine
- China
- ISO9001:2008
- One set China Reliable quality and Energy Saving jaw crusher machine for Chalk
- [email protected]
- 1320*2150*1175,1400x1850x1310,1450x2150x1175,1920x1460x1840,customized
- Within 5 working days
- paypal,UnionPay, Visa/MasterCard, Amex, Discover,T/T
- 118
- Shandong Brawny Industrial Co.,Ltd2020-07-10 09:46:19
Welcome to my shop! Glad to serve you! Please send your question!
Product Description
OverView
Jaw crushers are typically used as primary crushers, or the first step in the process of reducing rock. They typically crush using compression. The rock is dropped between two rigid pieces of metal, one of which then move inwards towards the rock, and the rock is crushed because it has a lower breaking point than the opposing metal piece.
Jaw crusher movement is obtained by using a pivot point located at one end of the “swing jaw”, and an eccentric motion located at the opposite end.
Features
1. High ratio of crushing,
2. Even final size,
3. Simple structure,
4. Reliable working condition,
5. Easy maintenance, 6. Low operating cost.
Working Principle
The motor transmits power through belt, drives the moving jaw to do periodic motion towards the fixed jaw by the eccentric shaft. The angle between toggle plate and moving jaw plate increases when moving jaw moves . So the moving jaw moves towards the fixed jaw. The stuff will be crushed in this process. The angle between toggle plate and moving jaw decreases when moving jaw moves down, the moving jaw moves leaves fixed jaw by pulling rod and spring, the final crushed stuff will be discharged from the outlet.
Model |
Max. Feeding Size (mm) |
Adjustable Discharge opening (mm) |
Capacity (t/h) |
Motor Power (kW) |
Overall Dimensions (mm) |
Weight (t) |
PE250×400 |
200 |
20-60 |
5-20 |
15 |
1150×1275×1240 |
2.8 |
PE250x1000 |
210 |
15-50 |
15-50 |
30 |
2790x2670x1380 |
6.5 |
PE400×600 |
350 |
40-100 |
15-60 |
30 |
1700×1732×1653 |
6.5 |
PE500×750 |
425 |
50-100 |
50-100 |
55 |
2035×1921×2000 |
10.3 |
PE600×900 |
500 |
65-160 |
60-130 |
75 |
2290×2206×2370 |
15.5 |
PE750×1060 |
630 |
80-140 |
110-250 |
110 |
2620×2302×3110 |
26.7 |
PE900×1200 |
750 |
100-200 |
160-380 |
130 |
3789×2826×3025 |
51 |
PE1000×1200 |
850 |
200-300 |
315-550 |
130 |
3889×2826×3025 |
56 |
PE1200×1500 |
1020 |
150-350 |
400-800 |
200 |
4200×3750×3820 |
88 |
About Us
Henan LIMING Heavy Industry Science and Technology Co. LTD which mainly manufacture large and medium-sized crushing and grinding equipments was founded in 1987. It is a modern joint-stock corporation with research, manufacturing and sales together. The Headquarter is located in HI-TECH Industry Development Zone of Zhengzhou and covers 80000 m ². Another workshop in Shangjie Industry Park covers 67000 m ². Over the past 30 years, our company adheres to modern scientific management system, precision manufacturing, pioneering and innovation. Now LIMING has become the leader in domestic and oversea machinery manufacturing industry.
LIMING brings a large number of high-qualification talents together. Bai Yinghui, general research and development engineer, is a well-known expert in crushing and grinding area who won the youth medal of technology of the state council and receives special government allowance. LIMING owns an experienced service team, offering the customer free design and professional skill training and live guide for installation and debugging. The company's service networks have spread all over the country. Established client files, and mix the traditional door-to-door service with online service together, complementary the advantages. LIMING has won high recognition from clients.
The company mainly manufactures mobile crushers, stationary crushers, sand-making machines, grinding mills and complete plants that are widely used in mining, construction, highway, bridge, coal, chemical, metallurgy, refractory matter, etc. Product quality is life, and scientific innovation is motive power. LIMING got ISO international quality system certification, European Union CE certification and Russian GOST certification. The company has strong research and development strength and innovation.
Over the past 26 years, our company adheres to modern scientific management system, precision manufacturing, pioneering and innovation. Now LIMING has become the leader in domestic and oversea machinery manufacturing industry.
Our ServicesOur services
High quality service is what we are pursuing. Our service is available all around the world. And our high quality service team is ready to provide you with fast and efficient service from the tailored solutions for competitive production process to free training of complete plant installation
1) Pre-sale service:Freely provide project designing, process designing, choosing suitable equipment for you.
2) Medium-sales service: Accompany you to complete the acceptance of the equipment,draft the construction scheme and detailed process, and complete process of export stone and sand making production line.
3) After-sales service: We sent engineer to the scene to guide installation, debugging and training operators.
Service supervision
Any dissatisfaction on service attitude, service skills, quality and morality of our technical staff , please feel free to contact us by
dialing 24 hours hot line;:China Reliable quality and Energy Saving jaw crusher machine for Chalk68911957 for stone and sand making production line.
CertificationsCertifications
The General Research Institute of Liming Heavy Industry China Reliable quality and Energy Saving jaw crusher machine for Chalkes on research and development of advanced technology and customer-oriented products as well as building up core competitiveness to makes Liming Heavy Industry a pioneer of the industry. By providing fundamental research results, the institute supports Liming Heavy Industry existing technology and products to be the world's top ones.
The General Research Institute of Liming Heavy Industry is the primary R&D department for technical research and technical management. It is responsible for developing technology applicable to Liming all products, conducting forefront technical research on new products and setting standards; researching vibration, impact, noise, hydraulic technology, power matching and energy saving, new materials and control systems, creating innovative technologies and conceptive products and building up a network-based special and generalized platform for experiments and tests so as to share general experiment and test results.
Packaging & Shipping
Delivery For Stationary Crushing Plant
Export standard container 20GP OR 40GP,40HQthe spare parts in wooden case.
Liming Products are exported to more than 100 countries and districts all over the world such as Russia, Central Asia, Middle East, Africa, Southeast Asia, Australia Union, North America, South America, etc.
How about the quality of your Crusher?
- Our crusher manufactured strictly according to national and international standard.
- We take a test on every crusher before delivery.
How about price of your crusher?
- We can give the lowest price of the crusher than market one.
- We do quotation of crusher as soon as possible for any custome.
- Discount of Crusher can be given according to quantity.
How about the after-sale service of your company?
- Our engineer is aviliable to installation Crusher overseas.
- The guarantee period of our Crusher is one year.
Our Products
Our Products Supply range of LIMING Company
1.Vibrating feeder, two types of GZD and ZSW to meet user’s different processing capacity;
2.First crushing: Jaw crusher, or Impact crusher, or cone crusher to meet user’s choise
3.Secondary crushing: fine jaw crusher, or impact crusher, or cone crusher(spring type, spring and hydraulic type, hydraulic type)
4.Vibrating screen, YK series, linear series, DF series
5.Belt conveyor, stationary type, or mobile type sand stone production line
6.Steel structures, such as feed-in and discharge hoppers, stairways, guardrails, maintenance board, steel channel, etc.
7.Electric control cabinet sand stone production line
8.Diesel power generation set for choosing.
Application of LIMING crusher
LIMING provides a complete line of stone production; the output is widely used in road, bridge, house, high building,
railway, highway, water project as the type of construction material, such as aggregate, foundation stone, etc.
Advantages of LIMING Brand of Stone Production Line
1.Complete stone production line, near to turn-key project;
2.Stationary type or mobile type for choosing
3.First class workmanship sand stone production line
4.Reliable quality with CE approved, reaching to European standard
5.Updating in design and function year by year, forms our own unique design by considering of saving more cost and improve the processing capacity for user’s consideration.
6.Invention technical patent kept sand stone production line.
More real pictures for our equipment working case
Mobile Crusher ——————————>> Click Here to Learn More
Jaw Crushers ——————————>> Click Here to Learn More
Impact crushers ————————————>> Click Here to Learn More
Cone Crushers ————————————>> Click Here to Learn More
More Case About Crushing Line Case For Your Reference >>
Jaw Stone Crushing Line Case ———————————————————>>
Impact Crushing Line Case For Complete Sand Production Lines ———————————>>
Cone Crushing Line Case Complete Sand Production Lines ———————————>>
Mobile Crusher Production Line Case Complete Stone Production Lines ———————————>>
Sand Production Line case Complete Sand Production Lines ———————————>>
If you would like to receive the price and detailed specifications of our Colombia sand making machine hot sale , please Leave Us a message Below!!
Some Industry News:
Jaw crusher is used for the first step of all kinds of ore rock breaking, and the compressive strength is not higher than 320 mpa can be all kinds of ores of one-time processing to moderate granularity, often with a cone crusher, counterattack crusher, sand making machine together form a complete set of sand production line, widely used in mining, metallurgy, chemical industry, building materials, electric power, water conservancy, transportation and other fields.
Application: application field, mining, coal mining, dry powder mortar, concrete mixing station, power plant desulfurization, quartz sand, etc
Material: pebble, granite, basalt, iron ore, limestone, quartz, diabase, iron ore, gold, copper, etc
Jaw crusher is mainly composed of frame, eccentric shaft, pulley, flywheel, side guard plate, bracket, bracket in the back seat, adjustable gap screw, reset spring, fixed jaw and movable jaw plate, etc.
Jaw crusher broken way for dynamic JiYaXing. Work, motor drive belt and pulley, make through eccentric shaft dynamic jaw movement up and down, when moving jaw rises, bracket and dynamic jaw Angle between larger, pushing dynamic jaw plate to the fixed jaw plate, material through between the two jaw extrusion, rolling, grinding, etc to achieve multiple broken; When the moving jaw downward, bracket and dynamic jaw Angle between smaller, under the action of moving jaw in a bar, spring away from fixed jaw plate, has broken material under the action of gravity, the discharging mouth of the lower jaw cavity free discharge. With the continuous rotation of the motor, moving jaw do periodic crushing and discharging, realize batch production.
Jaw Crusher Machine is fit for dry and wet sieving, classification of powdery, granular and filamentary materials and dehydration of materials. If fine sieving is required China Reliable quality and Energy Saving jaw crusher machine for Chalk can be satisfied by adopting high-efficiency screen mesh-cleaning device to improve the sieving. For wet sieving China Reliable quality and Energy Saving jaw crusher machine for Chalk is especially fit for separation of sludge (waste water) and preliminary compression of mixed matter of solid and liquid materials.
