China newest mineral processing jaw crusher machine with low crusher price
- Jaw Crusher Machine
Jaw Crusher Machine
- China
- CE/ISO9001:2000
- One set China newest mineral processing jaw crusher machine with low crusher price
- [email protected]
- 2290x2290x2400
- Within 5 working days
- paypal,UnionPay, Visa/MasterCard, Amex, Discover,T/T
- 75
- Shandong Brawny Industrial Co.,Ltd2020-07-10 09:46:19
Welcome to my shop! Glad to serve you! Please send your question!
Product Description
1. Introduction and Application of Jaw Crusher
Yufeng PE series jaw crushers are single toggle jaw crushers.It is one of the most commonly used crushers in industrial production. They are widely applied in coarse and medium reduction of various kinds of ores and rocks with compressive strength under 350 MPa. China China China newest mineral processing jaw crusher machine with low crusher price mineral processing jaw crusher machine with low crusher price mineral processing jaw crusher machine with low crusher price
PE series jaw crushers have a crushing chamber which is composed of a movable jaw, a stationary jaw and a edge plate. Driven by electric motor, via motorpully, V-belt and sheave driving eccentric shaft that make movable jaw move in accordance with pre-selected track cause crushing the material which are in the crushing chamber and setting the crushed material by the discharge gate. PE series jaw crushers have advanced features such as high reduction ratio, product size uniform, long service time, simple construction, outstanding reliability, easy maintenance, low energy consumption etc. Therefore, PE series jaw crushers are the top priority products as the primary crushing. They are widely applied in mining, road&railway, concrete, chemical and building material industries.
2. Yufeng brand Jaw Crusher Machine's working area
1. Jaw crusher is widely applied in mining, road&railway, concrete, chemical and building material industries.
2. Jaw crushers are used for crushing ores and rocks with various hardness
3. Jaw crushers can be used in concrete basis and steel structure basis
4. There are stationary, half-mobile and mobile applications
3. Features of Jaw Crusher Machine
1) High reliability; Stable performance
2)Adjustable for easy wear parts;Long service time
3) Simple structure;easy to operate;Easy adjustment;
4) ISO9001:2008,CE
5)Low cost, Easy to install
6)Large crushing ratio, even granularity, reliable operation, easy maintenance
China China China newest mineral processing jaw crusher machine with low crusher price mineral processing jaw crusher machine with low crusher price mineral processing jaw crusher machine with low crusher price
4. Structure of Jaw Crusher Machine
Main Frame: Fabricated from best quality steel plates specially designed
Eccentric Shaft: High quality eccentric shaft with heavy duty self aligning bearing to give trouble free running
Jaw Plates: Wear resistance manganese steel.
Side Plates: Uses manganese steels as material
Lubrications: Grease lubrication system guarantees safe operation
Toggle Plate: Cast in Special Cast Iron. Lubrication between Toggle Plate & Toggle Bearings by application of grease.
China China China newest mineral processing jaw crusher machine with low crusher price mineral processing jaw crusher machine with low crusher price mineral processing jaw crusher machine with low crusher price
5. Preparation Before Jaw Crusher Machine Working:
1). Assure the lubrication well, check whether it is with enough lubricating grease btw the toggle plate.
2). Check whether it is fasten well or not.
3). Check the protective device well or not
4). Check whether there is ore or other things at the crushing chamber.
China China China newest mineral processing jaw crusher machine with low crusher price mineral processing jaw crusher machine with low crusher price mineral processing jaw crusher machine with low crusher price
6. How to use Jaw Crusher Machine:
1). Putting the material after the smooth running.
2). Avoid putting the material from aside when the stone is evenly crushed in crushing chamber.
3). Generally, the bearing temperature is between 35°C and 70°C.
4). Stopping putting into material and the stone is fully crushed in chamber before closing the motor.
China China China newest mineral processing jaw crusher machine with low crusher price mineral processing jaw crusher machine with low crusher price mineral processing jaw crusher machine with low crusher price
7. Advantages of Jaw Crusher Machine:
Yufeng has introduced overseas technology of PE series jaw crushers. Unique jaw crusher principle, novel technology and structural parameter make the state-of-the-art performance.
PE series jaw crushers' main shaft is made of forging adopt quenching and tempering, main welding frame is entirely annealing, whole frame construction is robust and durable. Furthermore, the superior wear resistance material and fixed jaw, mobile jaw made of special process multiply service time over jaw made of ordinary manganese steel. PE series jaw crushers have advanced features such as high reduction ratio, product size uniform, long service time, simple construction, outstanding reliability, easy maintenance, low energy consumption etc. PE series are the top priority products as the primary crushing you should choose. China China China newest mineral processing jaw crusher machine with low crusher price mineral processing jaw crusher machine with low crusher price mineral processing jaw crusher machine with low crusher price
8. Lubrication of Jaw Crusher Machine
1). It often needs to be lubricated so that the crusher can be work well and used for long time.
2). The lubricating grease usually is calcium-sodium base grease, or calcium base grease, or sodium base grease
3). The bearing lubricating grease should be changed once every three months. jaw crusher plant, jaw crusher machine
China China China newest mineral processing jaw crusher machine with low crusher price mineral processing jaw crusher machine with low crusher price mineral processing jaw crusher machine with low crusher price
9. The factors infChina China newest mineral processing jaw crusher machine with low crusher price mineral processing jaw crusher machine with low crusher pricecing the capacity:
1). The raw material hardness
2). The raw material composition
3). The final product size after crushing
4). The raw material viscosity
5). The raw material moisture
China China China newest mineral processing jaw crusher machine with low crusher price mineral processing jaw crusher machine with low crusher price mineral processing jaw crusher machine with low crusher price
10. Technical parameters of Jaw Crusher Machine
Type |
Feed opening |
Max feeding size |
Adjusting range of discharge opening |
Capacity(t/h) |
Motor power |
Total weight |
Dimensions |
PE-150x250 |
150x250 |
125 |
10-40 |
1-3 |
5.5 |
0.6 |
720x660x850 |
PE-200x300 |
200x300 |
180 |
15-50 |
2-6 |
7.5 |
1 |
910x750x990 |
PE-200x350 |
200x350 |
180 |
18-70 |
3-10 |
11 |
1.3 |
1000x870x990 |
PE-250x400 |
250x400 |
210 |
20-60 |
5-20 |
15 |
2.8 |
1300x1090x1270 |
PE-400x600 |
400x600 |
340 |
40-100 |
16-60 |
30 |
7 |
1730x1730x1630 |
PE-500x750 |
500x750 |
425 |
50-100 |
40-110 |
55 |
12 |
1980x2080x1870 |
PE-600x900II |
600x900 |
500 |
65-160 |
50-180 |
55-75 |
17 |
2190x2206x2300 |
PE-600x900 |
600x900 |
500 |
75-200 |
60-200 |
75 |
20 |
2290x2290x2400 |
PE-750x1060 |
750x1060 |
630 |
80-140 |
115-330 |
110 |
29 |
2660x2430x 800 |
PE-870x1060 |
870x1060 |
660 |
200-260 |
290-336 |
110 |
31.5 |
2810x2430x2800 |
PE-900x1060 |
900x1060 |
685 |
230-290 |
160-400 |
110 |
33 |
2870x2420x2940 |
PE-900x1200 |
900x1200 |
750 |
95-165 |
220-450 |
110 |
52 |
3380x2870x3330 |
PE-1000x1200 |
1000x1200 |
850 |
195-265 |
315-500 |
110 |
55 |
3480x3876x3330 |
PE-1200x1500 |
1200x1500 |
1020 |
150-300 |
400-800 |
160 |
100.9 |
4200x3300x3500 |
PEX-150x750 |
150x750 |
120 |
18-48 |
8-25 |
15 |
3.8 |
1200x1530x1060 |
PEX-250x750 |
250x750 |
210 |
25-60 |
13-35 |
30 |
5.5 |
1380x1750x1540 |
PEX-250x1000 |
250x1000 |
210 |
25-60 |
16-52 |
37 |
7 |
1560x1950x1390 |
PEX-250x1200 |
250x1200 |
210 |
25-60 |
20-61 |
45 |
8.5 |
2140x1660x1500 |
PEX-300x1300 |
300x1300 |
250 |
20-90 |
16-105 |
75 |
11 |
2720x1950x1600 |
Pictures of Yufeng Jaw Crusher Machine
ZHENGZHOU YUFENG HEAVY MACHINERY CO., LTD
We can design flowchart and layout according to customers' need.If you want to learn more information,please contact us any time.
Whatsapp/Wechat/Viber 0086 13526817088
....
Jaw Crusher Machine is fit for dry and wet sieving, classification of powdery, granular and filamentary materials and dehydration of materials. If fine sieving is required China China newest mineral processing jaw crusher machine with low crusher price mineral processing jaw crusher machine with low crusher price can be satisfied by adopting high-efficiency screen mesh-cleaning device to improve the sieving. For wet sieving China China newest mineral processing jaw crusher machine with low crusher price mineral processing jaw crusher machine with low crusher price is especially fit for separation of sludge (waste water) and preliminary compression of mixed matter of solid and liquid materials.
hhhghj
Jaw Crusher Machine can do according to customers special demands. We provide our customers with high-quality Jaw Crusher Machine, advanced production technology and perfect after-sales services.China China newest mineral processing jaw crusher machine with low crusher price mineral processing jaw crusher machine with low crusher price Our well-equipped facilities and excellent quality control throughout all stages of production enables us to guarantee total customer satisfaction.
