Highly Effective Impact Fine Crusher

Impact Crusher is our improved product of crusher. Its biggest advantage is as follows: the product is of cubic shape without crack. The machine is of reasonable structure, wide use, high efficiency, simple operation and maintenance and excellent safe performance.

PCX highly effective impact fine crusher (the third generation sand making machine) is a new type sand making equipment developed by combining the domestic and overseas technology with the working conditions of related industries.
Impact fine crusher is used for fine crushing medium hard materials in concrete industry, such as limestone, plaster, clinker, mixed material, calcium phosphide, dolomite, and pearl ore, etc.

Impact Fine crusher is also applicable to building material, fertilizer, mine and fireproofing material industries.

Features of Highly Effective Impact Fine Crusher:
Highly effective impact fine crusher is a kind of efficient and energy-saving crushing machine.
Impact Fine crusher has the characteristics of simple structure, stable performance, high productivity, low energy consumption, and easy maintenance, etc.
The discharging materials are of small and equal size Our Impact Fine crusher hammer has long service life.
By using our efficient highly effective impact fine crusher, tertiary crushing can be changed to secondary crushing.

Technical Parameters:

A. Model: PCX 800×400

1.Size of feeding hole (mm): 400×185

2.Max. feeding Size (mm): 120

3.Discharging size (mm): Discharging size (mm)

4.Discharging Width Control (mm): Discharging Width Control (mm)

5.Productivity(t/h) of Cement Clinker: 20-30

6.Productivity(t/h) of imestone: 30-45

7.Productivity(t/h) of Glass sand: 35-45

8.Power(kw): 22-37

B. Model: PCX 800×600

1.Size of feeding hole (mm): 500×250

2.Max. feeding Size (mm): 180

3.Discharging size (mm): Discharging size (mm): ≤5

4.Discharging Width Control (mm): Discharging Width Control (mm): 5-20

5.Productivity(t/h) of Cement Clinker: 35-40

6.Productivity(t/h) of imestone: 40-55

7.Productivity(t/h) of Glass sand: 45-55

8.Power(kw): 37-45

C. Model: PCX 800×800

1.Size of feeding hole (mm): 550×330

2.Max. feeding Size (mm): 180

3.Discharging size (mm): Discharging size (mm): ≤5

4.Discharging Width Control (mm): Discharging Width Control (mm): 5-20

5.Productivity(t/h) of Cement Clinker: 35-45

6.Productivity(t/h) of imestone: 60-65

7.Productivity(t/h) of Glass sand: 55-65

8.Power(kw): 37-45

D. Model: PCX 1010×1010

1.Size of feeding hole (mm): 1000×350

2.Max. feeding Size (mm): 180

3.Discharging size (mm): Discharging size (mm): ≤5

4.Discharging Width Control (mm): Discharging Width Control (mm): 5-20

5.Productivity(t/h) of Cement Clinker: 45-55

6.Productivity(t/h) of imestone: 60-75

7.Productivity(t/h) of Glass sand: 65-75

8.Power(kw): 45-55

E. Model: PCX 1200×1000

1.Size of feeding hole (mm): 1200×400

2.Max. feeding Size (mm): 180

3.Discharging size (mm): Discharging size (mm): ≤5

4.Discharging Width Control (mm): Discharging Width Control (mm): 5-20

5.Productivity(t/h) of Cement Clinker: 80-110

6.Productivity(t/h) of imestone: 80-100

7.Productivity(t/h) of Glass sand: 80-100

8.Power(kw): 90-110

F. Model: PCX 1200×1200

1.Size of feeding hole (mm): 1200×450

2.Max. feeding Size (mm): 180

3.Discharging size (mm): Discharging size (mm): ≤5

4.Discharging Width Control (mm): Discharging Width Control (mm): 5-20

5.Productivity(t/h) of Cement Clinker: 100-110

6.Productivity(t/h) of imestone: 90-100

7.Productivity(t/h) of Glass sand: 90-120

8.Power(kw): 110-132

G. Model: PCX 1400×1400

1.Size of feeding hole (mm): 1500×500

2.Max. feeding Size (mm): 190

3.Discharging size (mm): Discharging size (mm): ≤5

4.Discharging Width Control (mm): Discharging Width Control (mm): 5-20

5.Productivity(t/h) of Cement Clinker: 100-150

6.Productivity(t/h) of imestone: 100-150

7.Productivity(t/h) of Glass sand: 120-150

8.Power(kw): 160

H. Model: PCX 1600×1600

1.Size of feeding hole (mm): 1600×550

2.Max. feeding Size (mm): 190

3.Discharging size (mm): Discharging size (mm): ≤5

4.Discharging Width Control (mm): Discharging Width Control (mm): 5-20

5.Productivity(t/h) of Cement Clinker: 170-210

6.Productivity(t/h) of imestone: 190-250

7.Productivity(t/h) of Glass sand: 190-250

8.Power(kw): 250

I. Model: PCX 1800×1800

1.Size of feeding hole (mm): 1800×800

2.Max. feeding Size (mm): 190

3.Discharging size (mm): Discharging size (mm): ≤5

4.Discharging Width Control (mm): Discharging Width Control (mm): 5-20

5.Productivity(t/h) of Cement Clinker: 250-270

6.Productivity(t/h) of imestone: 280-310

7.Productivity(t/h) of Glass sand: 280-310

8.Power(kw): 280

Main technical parameters:

...

Fine Crusher, gold hammer mill price is applicable for both dry and wet crushing.Zinc crusher,impact crusher for rock stone grinder hammer mill crusher machine is widely used for medium or fine crushing Fine Crusher for medium hard and brittle materials by departments of mine, cement,Zinc crusher,impact crusher for rock stone coal,building material, metallurgy, Fine Crusher chemical industry, road construction,gas chemical industry and Zinc crusher,impact crusher for rock stone thermal power generation, etc. Coal gangue,coke, slag, limestone, phosphate rock, salt, whiting, gypsum stains,alum, brick and tile, etc.
HSFGYGDJ
When the Fine Crusher is working, materials are crushed primarily in the first crushing chamber by the high speed moving rotor against the hammer, and then enter the secondary chamber for fine crushing, at last, the final materials are discharged.Zinc crusher,impact crusher for rock stone adopts "stone-stone" principle with a huge arc-shaped crushing cavity, which is a screen cavity with grate seam
