Hot selling high quality water treatment circular vibrating screen
- Circular Vibrating Screen
Circular Vibrating Screen
- China
- CE ISO
- One set Hot selling high quality water treatment circular vibrating screen
- [email protected]
- Vary
- Within 5 working days
- paypal,UnionPay, Visa/MasterCard, Amex, Discover,T/T
- 89
- Shandong Brawny Industrial Co.,Ltd2020-07-10 09:46:19
Welcome to my shop! Glad to serve you! Please send your question!
Product Description
Hot selling high quality water treatment circular vibrating screen
This series of vibrating screen is also referred to as circular vibrating screen because its movement is approximate to be a circular motion, and it is an efficient new vibrating screen with several layers. The machine uses an eccentric vibration exciter and tire couplings to improve the service life of equipment; the equipped spring damping device can effectively reduce the impact on the foundation and lower the vibration noise.
Working Principle of water treatment circular vibrating screen:
When circular vibrating screen on operation , first the materials will feed on circular vibrating screen mesh , and the materials will separated uniformly on screen mesh plates . The rolling bearing of circular vibrating screen will stressed by highly mostly shock-type loads . And more , the circular vibrating screen bearing ,while rotating about their own axis ,going a way of circular ,elliptical or linear vibrating motion . This results in high radial accelerations which additionally stress the bearings , and especially the cages considerably. The operating speeds are usually in a very high condition . As a result, the bearing temperatures are up to 20 to 30 degrees Kelvin higher than in normal applications. In addition, considerable misalignments between the bearing locations and considerable shaft deflections have to be accommodated.
Features of water treatment circular vibrating screen:
1 Used the eccentric block as excitation force ,strong excitation .
2 High strength bolt connection between sieve beam and screen box ,no welding .
3 Simple structure ,easy maintenance .
4 Use tyre couplings ,flexible connection ,stable operation .
5 High screening efficiency ,large handling capacity ,long life span
The main technical data of water treatment circular vibrating screen:
Type |
Sieve layer |
Sieve area (m2) |
Mesh size (mm) |
Max. Feeding size (mm) |
Capacity (t) |
Vibrating frequency (r/min) |
Double amplitude (mm) |
Power (kw) |
Sieve obliquity (o) |
Sieve specification (mm) |
Weight (kg) |
2YK1230 |
2 |
7.2 |
4-50 |
400 |
12-78 |
800-970 |
8 |
7.5 |
20 |
1200*3000 |
4200 |
3YK1230 |
3 |
10.8 |
4-50 |
400 |
13-80 |
800-970 |
8 |
7.5 |
20 |
1200*3700 |
4600 |
2YK1237 |
2 |
8.88 |
4-50 |
400 |
15-86 |
800-970 |
8 |
7.5 |
20 |
1200*3700 |
4600 |
3YK1237 |
3 |
13.22 |
4-50 |
400 |
16-90 |
800-970 |
8 |
7.5 |
20 |
1500*3500 |
5200 |
2YK1535 |
2 |
10.5 |
5-50 |
400 |
20-125 |
800-970 |
8 |
11 |
20 |
1500*3500 |
5890 |
3YK1535 |
3 |
15.75 |
5-50 |
400 |
21-125 |
800-970 |
8 |
11 |
20 |
1500*3500 |
6700 |
2YK1545 |
2 |
13.5 |
5-50 |
400 |
22-150 |
800-970 |
8 |
15 |
20 |
1500*4500 |
6330 |
3YK1545 |
3 |
20.25 |
5-50 |
400 |
22-150 |
800-970 |
8 |
15 |
20 |
1500*4500 |
6800 |
4YK1545 |
4 |
27 |
5-50 |
400 |
22-155 |
800-970 |
8 |
18.5 |
20 |
1500*4500 |
7800 |
2YK1548 |
2 |
14.4 |
5-50 |
400 |
23-162 |
800-970 |
8 |
15 |
20 |
1500*4800 |
6980 |
3YK1548 |
3 |
21.6 |
5-50 |
400 |
23-162 |
800-970 |
8 |
15 |
20 |
1500*4800 |
7700 |
4YK1548 |
4 |
28.8 |
5-50 |
400 |
23-162 |
800-970 |
8 |
18.5 |
20 |
1500*4800 |
8700 |
2YK1848 |
2 |
17.28 |
5-80 |
400 |
25-206 |
750 |
8 |
15 |
20 |
1800*4800 |
9080 |
3YK1848 |
3 |
25.92 |
5-80 |
400 |
32-276 |
750 |
8 |
18.5 |
20 |
1800*4800 |
9600 |
4YK1848 |
4 |
34.54 |
5-80 |
400 |
32-285 |
750 |
8 |
22 |
20 |
1800*4800 |
11100 |
2YK1854 |
2 |
19.44 |
5-80 |
400 |
32-312 |
800-970 |
8 |
18.5 |
20 |
1800*5400 |
10150 |
3YK1854 |
3 |
29.16 |
5-80 |
400 |
32-312 |
800-970 |
8 |
22 |
20 |
1800*5400 |
10840 |
4YK1854 |
4 |
38.88 |
5-80 |
400 |
32-336 |
800-970 |
8 |
30 |
20 |
1800*5400 |
12840 |
2YK2160 |
2 |
25.2 |
5-100 |
400 |
50-475 |
970 |
8 |
30 |
20 |
2100*6000 |
11780 |
3YK2160 |
3 |
37.8 |
5-100 |
400 |
50-475 |
970 |
8 |
30 |
20 |
2100*6000 |
12800 |
4YK2160 |
4 |
50.4 |
5-100 |
400 |
50-497 |
970 |
8 |
37 |
20 |
2100*6000 |
14800 |
2YK2460 |
2 |
28.8 |
5-100 |
400 |
65-550 |
970 |
8 |
37 |
20 |
2400*6000 |
15600 |
3YK2460 |
3 |
43.2 |
5-100 |
400 |
70-620 |
970 |
8 |
37 |
20 |
2400*6000 |
17600 |
4YK2460 |
4 |
57.6 |
5-100 |
400 |
80-680 |
970 |
8 |
45 |
20 |
2400*6000 |
19600 |
Your desire, we design. We are one of the most professional manufacturers of water treatment circular vibrating screen.
Circular Vibrating Screen have many layers and high efficiency. Hot selling high quality water treatment circular vibrating screen is adopts the barrel type of eccentric shaft vibration exciter and eccentric block to adjust the swing. Circular Vibrating Screen is of the flowing characteristics, the screening line is long and specification of materials screened is various, and it is also of reliable structure, strong exciting force, high screening efficiency, low vibrating noise, long durability, convenient maintenance, safe operation, etc, and the vibrating screen is widely used for screening in wide range including mines, building material, transportation, energy sources, chemical industry, etc. Hot selling high quality water treatment circular vibrating screen consists of screen box, supporting device, vibration exciter, transmission part, etc.The barrel-type vibration exciter is installed in the middle part of the machine. During normal operation, the vibration of exciter will drive the screen mesh fixed on the screen box vibrate, and then materials will be screened. The big and small materials fall from the upper side and lower side of the screen to get them separated.
JHGVGDD
Circular Vibrating Screen is single-axis circular-movement inertial vibrating screen, the working of circular vibrating screen depends on inertial motor and inertial strength produced by eccentric plate,Hot selling high quality water treatment circular vibrating screen because of the vibration of screen box, the materials are threw out, so that materials of certain size go through the screen mesh, and the screening aim is realized. Circular Vibrating Screen Since the magnetic exciter is installed on the gravity center of screen box, the two long elliptical axis form a shape like a Chinese character, Hot selling high quality water treatment circular vibrating screen and the upper of long elliptical axis in inlet end is in the same direction with the outlet, which favors the spread of materials which is in the screen box.
AFDFVCF
